RS84 version3 75% kit (Salvage Update)
« on: Tue, 14 July 2015, 11:58:42 »
UPDATE 2016-05-02

RS84 group buy salvage signup form:

http://goo.gl/forms/fDbzHlOJ2Z


The form will stay open for at least a couple weeks



ORDER HERE

Orders close 10 August.
Invoices will be sent out daily and are DUE UPON RECEIPT.
There will be an additional $10 fee per kit to cover the groups shipping from China to USA. All USA orders will be send by PRIORITY, single kit medium flatrate $13, or 2 kit in large flatrate $16. International orders sent by first class non insured parcel, $30-35.

Features RGB led on the bottom of the PCB which could be controlled by the keys or with a remote wireless controller with support 16 colors and adjustable brightness. PCB supports choices for many layout variations including ISO. 3mm normal led for in switch backlight, with 3 modes: always on, breathing light, light when type with adjustable speed of  the dynamic lighting. New version 3 case tray combines the best aspects of the Special edition and standard edition from previous.

DIY set will include 1 pcb, 1 frosted white acrylic tray case, 1 remote for rgb control for $140.




4 color choice of plate available: black, red, silver, grey. Optional item, is $22 extra.
4 color choice of feet available: black, red, silver, grey. Optional item, is $5 extra for pair. (Please note, without feet the case will have 0° angle)

ORDER HERE
« Last Edit: Mon, 02 May 2016, 14:34:08 by HoffmanMyster »

Offline iamtootallforthis

  • Something a lot Funnier
  • * Global Moderator
  • Posts: 4582
  • Location: West Palm Beach, FL
  • I like green stuffs.
    • WTB/WTTF Thread
Re: RS84 version3 75% kit
« Reply #1 on: Tue, 14 July 2015, 12:20:42 »
I don't think I'll be able to pass this up.

Offline lishi

  • Posts: 164
  • Location: N O V A
  • Luxury Taste Buds
    • Personal Website
Re: RS84 version3 75% kit
« Reply #2 on: Tue, 14 July 2015, 12:47:09 »
What will be soldered onto the PCB already? SMD components? Diodes? LED's? Nothing?
Duck Viper V2 - 68g Cherry RGB Silent Red | Noxary X60 Dark Gray HHKB x2 | Revo RJ Pink + Blue Soon(TM)

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Thread Starter
  • Posts: 8199
  • Location: USA
Re: RS84 version3 75% kit
« Reply #3 on: Tue, 14 July 2015, 12:52:17 »
All SMD components come presolder, such as the contoller chip, smd rgb led, diode, resistor, USB connector, etc... you only need to solder the MX (compatible) keyswitch, and add in switch LED if you desire full backlighting.

Offline Blackehart

  • Posts: 316
  • Location: Southern California, USA
  • Booty Aficionado Extraordinaire
Re: RS84 version3 75% kit
« Reply #4 on: Tue, 14 July 2015, 13:00:40 »
any chance for case only?

Offline fliptrik

  • Posts: 87
  • Location: Los Angeles, California
Re: RS84 version3 75% kit
« Reply #5 on: Tue, 14 July 2015, 13:02:19 »
Oh boy. This puppy will be mine. Do you know when the estimated shipping date is? Is it just as soon as the group buy ends? And are there any pictures of the different plate colors? I'd like to see the difference between silver and grey if possible.

Offline mattyIce

  • Posts: 11
Re: RS84 version3 75% kit
« Reply #6 on: Tue, 14 July 2015, 13:50:28 »
In for one thanks!

Offline arcvile

  • * Destiny Supporter
  • Posts: 33
Re: RS84 version3 75% kit
« Reply #7 on: Tue, 14 July 2015, 16:01:49 »
thanks for this, I'm totally in for 1

Offline Bloo

  • Posts: 25
  • Location: Cold.
Re: RS84 version3 75% kit
« Reply #8 on: Tue, 14 July 2015, 21:17:08 »
I got mine through Ivan's last group buy.  Good board so far and the buy itself was pretty fast and almost entirely hypeless and without drama.  I highly recommend.
« Last Edit: Fri, 25 September 2015, 07:10:58 by Bloo »

Offline Thumper_

  • Posts: 218
  • Location: Germany
  • Spend all my money.
Re: RS84 version3 75% kit
« Reply #9 on: Wed, 15 July 2015, 00:50:38 »
How many of those case leds are on the front side ?

Offline lishi

  • Posts: 164
  • Location: N O V A
  • Luxury Taste Buds
    • Personal Website
Re: RS84 version3 75% kit
« Reply #10 on: Wed, 15 July 2015, 08:17:12 »
Any pictures of the plates?
Duck Viper V2 - 68g Cherry RGB Silent Red | Noxary X60 Dark Gray HHKB x2 | Revo RJ Pink + Blue Soon(TM)

Offline ccarlitos2

  • Posts: 879
  • Location: Not in the Tardis
Re: RS84 version3 75% kit
« Reply #11 on: Wed, 15 July 2015, 08:28:31 »
So. Much. Want. But sadly this ends the day before I go back to work :(
HHKB Pro 1| Poker 2(MX Browns)| Leopold FC200R (MX Blue)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
"Yup, that tasted purple" -Lulu

Flickr: https://www.flickr.com/photos/138889771@N05/

Offline jaemzp

  • Posts: 45
  • Location: Sydney, Australia
Re: RS84 version3 75% kit
« Reply #12 on: Wed, 15 July 2015, 08:28:51 »
US Only :( :( :(

Offline nmur

  • ಠ_ಠ
  • Posts: 1434
  • Location: Sydney
Re: RS84 version3 75% kit
« Reply #13 on: Wed, 15 July 2015, 08:52:13 »
Oh man this looks nice! Shame about shipping restriction though. Hope everything goes well.
wtb/wttf: milk blue clack (t), blank blue realforce set

Offline absyrd

  • CPT HYPE PADAWAN
  • Posts: 3070
  • Location: Philly Burbs
  • HHKB4LYFE
Re: RS84 version3 75% kit
« Reply #14 on: Wed, 15 July 2015, 08:54:48 »
Any pictures of the plates?

PCB mount?
My wife I a also push her button . But now she have her button push by a different men. So I buy a keyboard a mechanicale, she a reliable like a Fiat.

Offline azhdar

  • Praise the AZERTY god
  • Posts: 2366
  • Location: France
  • 65% Enlighted
Re: RS84 version3 75% kit
« Reply #15 on: Wed, 15 July 2015, 08:59:49 »
Any pictures of the plates?

PCB mount?

There's a plate price in the Order Form

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #16 on: Thu, 16 July 2015, 11:42:16 »
I'm in for one
I liek keyboards

Offline Rodgaroon

  • Posts: 273
  • Location: Toronto, Ontario, Canada
  • Size matters, just ask my wife.
Re: RS84 version3 75% kit
« Reply #17 on: Thu, 16 July 2015, 12:53:14 »
I need to learn how to solder. Sad Face.
G6v2 (MX Black) | Poker II (MX Brown) | Compact SQ (MX Clears 62g)

Offline lishi

  • Posts: 164
  • Location: N O V A
  • Luxury Taste Buds
    • Personal Website
Re: RS84 version3 75% kit
« Reply #18 on: Thu, 16 July 2015, 13:50:03 »
Didn't get an invoice yet, are they supposed to go out the day we fill out the form?
Duck Viper V2 - 68g Cherry RGB Silent Red | Noxary X60 Dark Gray HHKB x2 | Revo RJ Pink + Blue Soon(TM)

Offline iamtootallforthis

  • Something a lot Funnier
  • * Global Moderator
  • Posts: 4582
  • Location: West Palm Beach, FL
  • I like green stuffs.
    • WTB/WTTF Thread
Re: RS84 version3 75% kit
« Reply #19 on: Thu, 16 July 2015, 13:51:45 »
SEE BELOW
« Last Edit: Thu, 16 July 2015, 13:58:13 by iamtootallforthis »

Offline Glissant

  • Posts: 1976
  • Location: Oslo, Norway
Re: RS84 version3 75% kit
« Reply #20 on: Thu, 16 July 2015, 13:54:33 »
Invoices will be sent out daily and are DUE UPON RECEIPT.

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #21 on: Thu, 16 July 2015, 14:56:09 »
Judging on the picture it looks like the PCB is set up for PCB mount switches. Is this correct and the reason why the plate is optional? Are stabilizers included? Just wondering so I can order parts.
I liek keyboards

Offline Glissant

  • Posts: 1976
  • Location: Oslo, Norway
Re: RS84 version3 75% kit
« Reply #22 on: Thu, 16 July 2015, 15:11:15 »
Yes, the PCB is set up for PCB mount switches. No you don't get stabilizers in this kit.

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #23 on: Thu, 16 July 2015, 15:18:09 »
Is there anywhere besides GON and Winkeyless that sell PCB mount stabilizers?
I liek keyboards

Offline a-c

  • Posts: 196
  • Location: USA
Re: RS84 version3 75% kit
« Reply #24 on: Thu, 16 July 2015, 16:31:18 »
Is there anywhere besides GON and Winkeyless that sell PCB mount stabilizers?

www.ortholinearkeyboards.com has 2u PCB stabilizers, but he only seems to sell them with the Planck Universal top plate (since it needs one). You would just need longer wires for spacebar. Not sure if the wires for the plate mount ones are the same but he does have those too.
« Last Edit: Thu, 16 July 2015, 16:33:40 by a-c »

Offline rpeterclark

  • Posts: 354
  • Location: Florida
  • RPTR ❌
Re: RS84 version3 75% kit
« Reply #25 on: Thu, 16 July 2015, 16:46:22 »
Is there anywhere besides GON and Winkeyless that sell PCB mount stabilizers?

www.ortholinearkeyboards.com has 2u PCB stabilizers, but he only seems to sell them with the Planck Universal top plate (since it needs one). You would just need longer wires for spacebar. Not sure if the wires for the plate mount ones are the same but he does have those too.

Also SPRiT: https://geekhack.org/index.php?topic=60887.0 , available on the order form.

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #26 on: Thu, 16 July 2015, 20:01:25 »
Is there anywhere besides GON and Winkeyless that sell PCB mount stabilizers?

www.ortholinearkeyboards.com has 2u PCB stabilizers, but he only seems to sell them with the Planck Universal top plate (since it needs one). You would just need longer wires for spacebar. Not sure if the wires for the plate mount ones are the same but he does have those too.

Thanks for the info. The ortholinear stabs are plate mount I believe and I'm planning on not doing a plate for this res scarf. I found the part numbers for pcb mount stabs and found that Mouser has them in stock. I have the capabilities to make my own wires.
I liek keyboards

Offline ph3nomzlol

  • Posts: 30
  • Location: Texas
  • Ruckus
Re: RS84 version3 75% kit
« Reply #27 on: Sat, 18 July 2015, 00:15:26 »
Is there anywhere besides GON and Winkeyless that sell PCB mount stabilizers?

Check out Sprit's GB threads.  I purchased some VERY nice Gold PCB stabs (he has OG non-gold stabs as well) from him not too long ago.  His shipping speeds are hit or miss though, but for the most part, I've ordered from him twice and never really had any issues to speak of.

Offline wangbwhz

  • Posts: 141
  • Location: Singapore
Re: RS84 version3 75% kit
« Reply #28 on: Sat, 18 July 2015, 09:55:21 »
sad to hear the shipping restriction all the best to u
My Precious¬

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Thread Starter
  • Posts: 8199
  • Location: USA
Re: RS84 version3 75% kit
« Reply #29 on: Sat, 18 July 2015, 10:37:18 »
For international, if you are good with paying the $30-35 shipping price then by all means.
These are set up for PCB mount, so the plate is entirely unnecessary and why it is an optional. PCB mount Cherry stabs are required, no other stab types will work even with plate.

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #30 on: Sat, 18 July 2015, 10:52:07 »
For international, if you are good with paying the $30-35 shipping price then by all means.
These are set up for PCB mount, so the plate is entirely unnecessary and why it is an optional. PCB mount Cherry stabs are required, no other stab types will work even with plate.

Awesome thanks for the info. Can't wait!
I liek keyboards

Offline absyrd

  • CPT HYPE PADAWAN
  • Posts: 3070
  • Location: Philly Burbs
  • HHKB4LYFE
Re: RS84 version3 75% kit
« Reply #31 on: Sat, 18 July 2015, 10:53:30 »
For international, if you are good with paying the $30-35 shipping price then by all means.
These are set up for PCB mount, so the plate is entirely unnecessary and why it is an optional. PCB mount Cherry stabs are required, no other stab types will work even with plate.

PCB mount is better anyhow! Soft to the feels.
My wife I a also push her button . But now she have her button push by a different men. So I buy a keyboard a mechanicale, she a reliable like a Fiat.

Offline Johan

  • Posts: 241
  • Location: Stockholm, Sweden.
Re: RS84 version3 75% kit
« Reply #32 on: Sat, 18 July 2015, 11:26:41 »
So to make this a working keyboard all I need is switches and stabs?
Uh, stuff.

Offline azhdar

  • Praise the AZERTY god
  • Posts: 2366
  • Location: France
  • 65% Enlighted
Re: RS84 version3 75% kit
« Reply #33 on: Sat, 18 July 2015, 11:45:21 »
So to make this a working keyboard all I need is switches and stabs?

Caps can be usefull too, unless you have mx compatible fingers ;)

Offline getf

  • Posts: 95
  • In Rod We Trust
Re: RS84 version3 75% kit
« Reply #34 on: Sun, 19 July 2015, 10:04:05 »
This might be a silly question, but is hardware included to mount the PCB/Plate into the acrylic case tray? (screws of some sort)

Offline Glissant

  • Posts: 1976
  • Location: Oslo, Norway
Re: RS84 version3 75% kit
« Reply #35 on: Sun, 19 July 2015, 10:28:46 »
Do you have examples of the difference in the color of the feet between gray and silver?

Edit: I saw this in the other thread.

« Last Edit: Mon, 20 July 2015, 00:45:18 by Glissant »

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Thread Starter
  • Posts: 8199
  • Location: USA
Re: RS84 version3 75% kit
« Reply #36 on: Mon, 20 July 2015, 09:55:17 »
Yes the kit come with m1.5 hex bolt to mount pcb to tray.

Offline Megaweapon

  • Posts: 185
Re: RS84 version3 75% kit
« Reply #37 on: Mon, 20 July 2015, 10:45:45 »
PCB mount Cherry stabs are required, no other stab types will work even with plate.

Any chance of the stabs being added to this GB?  Would definitely make it more attractive to me.

Ancer Research Groop DFK191ABA11 IBM Model M13 Part 92G7461 (white) Rosewill RK-9000
Matias Tactile Pro 3 Apple Extended Keyboard II (ALPS)
Rosewill RK-9000I

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #38 on: Mon, 20 July 2015, 10:53:57 »
PCB mount Cherry stabs are required, no other stab types will work even with plate.

Any chance of the stabs being added to this GB?  Would definitely make it more attractive to me.

I found PCB Mount stabs on Mouser here. These came with a wire too. Unfortunately I wasn't able to find 6.25x wire for PCB mount stabs anywhere so I just ordered an extra set of the stabs to use and will attempt to make my own wire.
I liek keyboards

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Thread Starter
  • Posts: 8199
  • Location: USA
Re: RS84 version3 75% kit
« Reply #39 on: Mon, 20 July 2015, 11:08:09 »
I have loads of 6.25 PCB spacebar wires (the style that have switch clearance bend, can't be used with plates) left.

Offline Glissant

  • Posts: 1976
  • Location: Oslo, Norway
Re: RS84 version3 75% kit
« Reply #40 on: Mon, 20 July 2015, 12:37:51 »
So do you have an example of the difference between the gray and silver?
Is the bottom pair gray in that picture? I'm only asking so I am 100% sure I don't get dark gray when I would like light gray. And I don't want silver that's very shiny.
« Last Edit: Mon, 20 July 2015, 12:39:51 by Glissant »

Offline fliptrik

  • Posts: 87
  • Location: Los Angeles, California
Re: RS84 version3 75% kit
« Reply #41 on: Mon, 20 July 2015, 15:26:15 »
So do you have an example of the difference between the gray and silver?
Is the bottom pair gray in that picture? I'm only asking so I am 100% sure I don't get dark gray when I would like light gray. And I don't want silver that's very shiny.

I'm also looking for an example of the color difference. Shiny silver is not something I would be down with but a light gray silver would be cool.

Offline unipsykal

  • Posts: 157
  • Location: Ring of Fire
  • ghostly lurker
Re: RS84 version3 75% kit
« Reply #42 on: Tue, 21 July 2015, 02:19:24 »
So do you have an example of the difference between the gray and silver?
Is the bottom pair gray in that picture? I'm only asking so I am 100% sure I don't get dark gray when I would like light gray. And I don't want silver that's very shiny.

I'm also looking for an example of the color difference. Shiny silver is not something I would be down with but a light gray silver would be cool.


Here is what the silver plate looks like, the silver feet are similar.

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Thread Starter
  • Posts: 8199
  • Location: USA
Re: RS84 version3 75% kit
« Reply #43 on: Tue, 21 July 2015, 09:25:43 »
Yes silver is bright shiny, grey is like gunmetal.

Offline Glissant

  • Posts: 1976
  • Location: Oslo, Norway
Re: RS84 version3 75% kit
« Reply #44 on: Tue, 21 July 2015, 10:35:36 »
Perfect. Thanks!

Offline Metr0

  • Posts: 86
  • Location: Durham, United Kingdom
  • HHKB or nuttin
Re: RS84 version3 75% kit
« Reply #45 on: Tue, 21 July 2015, 18:29:09 »
Is this only open to USA? Also will 1.8mm LEDs work instead of 3mm? Is a Teensy required? Does the aluminium case feet option contain 2 feet, Or do I need to order two?

Sorry for all the questions, first time building my own board from scratch!
« Last Edit: Tue, 21 July 2015, 18:52:08 by Metr0 »
[WTB] BLANK PINK HHKB ARROW CLUSTER

Offline Wannabe

  • Posts: 72
  • Location: U.S.A.
  • Independent Adjudicator
Re: RS84 version3 75% kit
« Reply #46 on: Wed, 22 July 2015, 09:21:21 »
Is this only open to USA? Also will 1.8mm LEDs work instead of 3mm? Is a Teensy required? Does the aluminium case feet option contain 2 feet, Or do I need to order two?

Sorry for all the questions, first time building my own board from scratch!

You don't need a teensy. Controller and all other SMD parts come presoldered.
I liek keyboards

Offline Invaderevan

  • Posts: 151
  • Location: DTX
Re: RS84 version3 75% kit
« Reply #47 on: Wed, 22 July 2015, 09:40:23 »
aw hell! an acrylic 75% board! This is exactly what I have been wanting for traveling. I am in here in the next week or so!

WTTF Ribbits, Ashen V2 MX, Bronins

Offline Metr0

  • Posts: 86
  • Location: Durham, United Kingdom
  • HHKB or nuttin
Re: RS84 version3 75% kit
« Reply #48 on: Wed, 22 July 2015, 09:59:31 »
Is this only open to USA? Also will 1.8mm LEDs work instead of 3mm? Is a Teensy required? Does the aluminium case feet option contain 2 feet, Or do I need to order two?

Sorry for all the questions, first time building my own board from scratch!

You don't need a teensy. Controller and all other SMD parts come presoldered.

Excellent, thank you!
[WTB] BLANK PINK HHKB ARROW CLUSTER

Offline Ngt

  • * Elevated Elder
  • Posts: 2348
  • Location: Lyon, France
Re: RS84 version3 75% kit
« Reply #49 on: Wed, 22 July 2015, 15:55:12 »
Hum I might be interested as well. I have to think this through.

Silenced Novatouch w/ Hack'd by Geeks

Sold: Ducky Zero Shine (Brown) | Poker 2 (Blue) | HHKB 55g Type-S
