Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1050 on: Tue, 06 May 2014, 22:36:08 »
"Red" is available for my GF.  However, Payment is my first point.
Love geekhack
mainboard, mouse, keyboard
hardware recovery and others

Offline BlueBär

  • Posts: 2156
  • Location: Germany, SB

Offline SpAmRaY

  • NOT a Moderator
  • * Certified Spammer
  • Posts: 14284
  • Location: ¯\(°_o)/¯
  • because reasons.......
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1052 on: Wed, 07 May 2014, 06:46:25 »
Anyone get one of these?

http://item.taobao.com/item.htm?spm=2013.1.0.0.OEDdax&id=38746408917&scm=1007.10039.737.0&pvid=ca181b91-0128-468d-9de5-58403815de91

Is that an aluminium case for 30$??

It looks like it :thumb:

But it seems to only be available in red and it is taobao after all so.....ymmv

Offline BlueBär

  • Posts: 2156
  • Location: Germany, SB
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1053 on: Wed, 07 May 2014, 07:01:34 »
It looks like it :thumb:

But it seems to only be available in red and it is taobao after all so.....ymmv

Yeah that price is extremly low. Maybe painted instead of anodized? If it is anodized you could reanodize it, and if it's painted you can probably remove the paint somehow, I wouldn't complain about that for this price :))

Hopefully it's legit :-X

Offline Thechemist

  • Posts: 244
  • Location: East Coast USA
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1054 on: Sat, 10 May 2014, 11:36:32 »





Offline agodinhost

  • Posts: 760
  • Location: Brazil, RJ
  • Soylent green is people ...
    • Dr Ian O Xaman
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1055 on: Sat, 10 May 2014, 11:40:14 »
Show Image

Show Image

Show Image

Show Image

Show Image

gosh!
AWESOME!!!
Building one square I2C keyboard with those 1200 switches (thanks JDCarpe)
GH60 |GH60-Alps |GH60-BT |GHPad/GHPad Alps |GH60-Case |Alps TKL |EL Wire |OS Controller, Round 2 |My Custom Keyboard |WTT/WTB

Offline swill

  • * Elevated Elder
  • Posts: 3332
  • Location: Canada eh
  • builder & enabler
    • swillkb.com
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1056 on: Sat, 10 May 2014, 21:36:24 »
I want this to go to GB already so I can buy one of these...

Why so long???

Offline WinterIsle

  • Posts: 136
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1057 on: Thu, 15 May 2014, 01:35:44 »
Received my GHpad pcb few weeks ago, I did a little mod and sanding since the plate layout is fixed and only clear acrylic case is available.
Sorry potatoes:






LED Effects Demo:

Offline bueller

  • MX baller
  • * Esteemed Elder
  • Posts: 3773
  • Location: Perth, Australia
  • Church of the Ergo Clear
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1058 on: Thu, 15 May 2014, 01:47:46 »
Surprised to see most people are making 6x4 pads, thought the majority would've made these for 60% boards. Dead keen to get mine built but I've been super lazy doing the CAD files for the case, kind of hoping that someone comes out with a CNC'ed case.
It's a good width!  If it's half-width it's too narrow, and full-width is too wide.

[WTT] bueller's trade thread - CLACKS WANTED

Offline feizor

  • Posts: 690
  • Location: Melbourne, Australia
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1059 on: Thu, 15 May 2014, 05:48:40 »
Received my GHpad pcb few weeks ago, I did a little mod and sanding since the plate layout is fixed and only clear acrylic case is available.
Sorry potatoes:

Show Image

Show Image

Show Image

Show Image


LED Effects Demo:

Acrylic works really well with LEDs.

Offline agodinhost

  • Posts: 760
  • Location: Brazil, RJ
  • Soylent green is people ...
    • Dr Ian O Xaman
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1060 on: Thu, 15 May 2014, 07:45:48 »
Acrylic works really well with LEDs.
When using good quality laser cutted acrylic yes.
Building one square I2C keyboard with those 1200 switches (thanks JDCarpe)
GH60 |GH60-Alps |GH60-BT |GHPad/GHPad Alps |GH60-Case |Alps TKL |EL Wire |OS Controller, Round 2 |My Custom Keyboard |WTT/WTB

Offline SpAmRaY

  • NOT a Moderator
  • * Certified Spammer
  • Posts: 14284
  • Location: ¯\(°_o)/¯
  • because reasons.......
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1061 on: Thu, 15 May 2014, 22:43:56 »
Not nearly as fancy as some but better than no case at all.

64888-0

Offline darknessaven

  • Posts: 3
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1062 on: Mon, 19 May 2014, 23:33:55 »
Is there any estimate for when there might be a group buy for a GHpad kit?

Offline slickmamba

  • Posts: 646
  • Location: US, San Diego/Berkeley/SF
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1063 on: Wed, 21 May 2014, 02:16:08 »
Awesome addition to the 60% boards! Can't wait to get on the GB!
Personal boards: HHKB Type-S 55g, ergodox 62g clears, Smallfry JD40 ???, Duck Viper 62g clears, Duck Viper 60g vintage Blacks, 456GT Vintage Black, 456GT Vintage Clears, Koala Vintage Browns, LZ-GH 62g Zealios, IBM SSK
Classroom boards: All those above, IBM Model M(Thanks Moose!), ??

Offline domoaligato

  • * Exquisite Elder
  • Posts: 1654
  • Location: USA
  • All your base are belong to us!
    • All your base are belong to us!
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1064 on: Sat, 31 May 2014, 03:50:05 »
Has anyone that is part of this dev group tested this with the gh60?
Does this still integrate with the gh60 or is this it's own standalone keypad?

I am good either way I was just curious.

If the pcb's seem to be finished for these I would like to either source a pcb or split the cost of a batch @ oshpark with a few other people.

Offline swill

  • * Elevated Elder
  • Posts: 3332
  • Location: Canada eh
  • builder & enabler
    • swillkb.com
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1065 on: Sat, 31 May 2014, 06:06:33 »
Has anyone that is part of this dev group tested this with the gh60?
Does this still integrate with the gh60 or is this it's own standalone keypad?

I am good either way I was just curious.

If the pcb's seem to be finished for these I would like to either source a pcb or split the cost of a batch @ oshpark with a few other people.

I'm in if another batch of pcbs is being produced.

Offline IvanIvanovich

  • Mr. Silk Underwear
  • Posts: 8199
  • Location: USA
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1066 on: Sun, 01 June 2014, 11:43:03 »
I still want one with SMD stuff done for me, but only 4x5.

Offline mashby

  • ** Moderator Emeritus
  • Posts: 2810
  • Location: Nashville, TN
  • What Up Shoney? (ツ)_/¯
    • Mashby
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1067 on: Thu, 03 July 2014, 09:43:20 »
I finally got off my duff and mailed my GH Pad to TheChemist to do the SMD work for me.

@IvanIvanovich -- It looks like the AboStudio Number Pad (which is a GH Pad) supports 4x5 layout.

Offline swill

  • * Elevated Elder
  • Posts: 3332
  • Location: Canada eh
  • builder & enabler
    • swillkb.com
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1068 on: Thu, 03 July 2014, 10:18:23 »
I really wish I got in on that last run of 4x6 pcbs.  I realized the run was going to happen like 2 days after it was finalized.  :(  Now it has been like 6 months and there has been no movement on this.


Offline jdcarpe

  • * Curator
  • Thread Starter
  • Posts: 8822
  • Location: Odessa, TX
  • Live long, and prosper.
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1069 on: Thu, 03 July 2014, 10:21:10 »
I really wish I got in on that last run of 4x6 pcbs.  I realized the run was going to happen like 2 days after it was finalized.  :(  Now it has been like 6 months and there has been no movement on this.




Just get one of these PCBs. They are GHpads : http://geekhack.org/index.php?topic=59950.0
KMAC :: LZ-GH :: WASD CODE :: WASD v2 :: GH60 :: Alps64 :: JD45 :: IBM Model M :: IBM 4704 "Pingmaster"

http://jd40.info :: http://jd45.info


in memoriam

"When I was a kid, I used to take things apart and never put them back together."

Offline swill

  • * Elevated Elder
  • Posts: 3332
  • Location: Canada eh
  • builder & enabler
    • swillkb.com
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1070 on: Thu, 03 July 2014, 15:40:23 »
I really wish I got in on that last run of 4x6 pcbs.  I realized the run was going to happen like 2 days after it was finalized.  :(  Now it has been like 6 months and there has been no movement on this.

Just get one of these PCBs. They are GHpads : http://geekhack.org/index.php?topic=59950.0

Sweet.  Thanks for pointing that out for me.  :)

Offline Sifo

  • Swaglord Yolomancer
  • * Exquisite Elder
  • Posts: 6336
  • Location: #GOLDSPRINGS, #LEGITBALLIN
  • beekeeper
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1071 on: Thu, 03 July 2014, 20:40:56 »
Man mine has all the SMD stuff done but I can't get it to even detect on my computer :( put it on hold for now :\ (it's the black pcb prototype)
(Forever) Illustrious.

Offline swill

  • * Elevated Elder
  • Posts: 3332
  • Location: Canada eh
  • builder & enabler
    • swillkb.com
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1072 on: Thu, 03 July 2014, 21:08:45 »
Man mine has all the SMD stuff done but I can't get it to even detect on my computer :( put it on hold for now :\ (it's the black pcb prototype)

Make sure the diodes are are connected the correct way.  I seem to remember there was a batch that was done with the diode silkscreen printed backwards.  Does anyone remember the details of that?  I remember others saying they had the same behavior and it had something to do with a mistake on the silkscreen and I think the fix was relatively easy (maybe time consuming though).

Anyone remember???  I am too lazy to find the post.    :blank:

Offline Sifo

  • Swaglord Yolomancer
  • * Exquisite Elder
  • Posts: 6336
  • Location: #GOLDSPRINGS, #LEGITBALLIN
  • beekeeper
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1073 on: Thu, 03 July 2014, 21:09:24 »
Man mine has all the SMD stuff done but I can't get it to even detect on my computer :( put it on hold for now :\ (it's the black pcb prototype)

Make sure the diodes are are connected the correct way.  I seem to remember there was a batch that was done with the diode silkscreen printed backwards.  Does anyone remember the details of that?  I remember others saying they had the same behavior and it had something to do with a mistake on the silkscreen and I think the fix was relatively easy (maybe time consuming though).

Anyone remember???  I am too lazy to find the post.    :blank:

Even if the diodes are on backwards, it should at least register on my PC no..? But no I have everything on correctly.
(Forever) Illustrious.

Offline bueller

  • MX baller
  • * Esteemed Elder
  • Posts: 3773
  • Location: Perth, Australia
  • Church of the Ergo Clear
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1074 on: Mon, 07 July 2014, 01:51:38 »
http://geekhack.org/index.php?topic=60290.0

Anyone got experience with 3D modelling and want to check my work?
It's a good width!  If it's half-width it's too narrow, and full-width is too wide.

[WTT] bueller's trade thread - CLACKS WANTED

Offline samwisekoi

  • MAWG since 1997
  • * Administrator
  • Posts: 2479
  • Location: Mt. View, California
  • Sorry, moving houses. Be back ASAP.
    • Tweet samwisekoi
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1075 on: Fri, 25 July 2014, 10:20:23 »
I missed much of the middle of this thread, but I now working on what is an extended-width version of the GHpad for use as a gamepad.

See thread here: input devices » Custom Programmable LH Gaming Pad

What I would like to do is add two columns to a fiver-row version of the GHpad.


samwisekoi gamepad v2.

 Electrically it should be simple to extend the rows -- but are there pad, pins, or traces where I could connect the two columns?  (Or the reverse if the PCB is row-wise instead of column-wise?)

Alternatively, if someone wants to point me to page nn of 32 in this or another thread, I am happy to look at circuit diagrams or schematics myself.

For general interest, the outcome of this request is likely to be some 1x5 or 1x6 extension PCBs that could be used by the inventive to extend the GHpad into other form factors as desired.

Thanks in advance, kind sers!

 - Ron | samwisekoi
I like keyboards and case modding.  Everything about a computer should be silent -- except the KEYBOARD!

'85 IBM F-122/Soarer Keyboard |  Leopold FC200 TKL (Browns) + GH36 Keypad (Browns/Greens) | GH-122 (Whites/Greens) with Nuclear Data Green keycaps in a Unicomp case

Offline jdcarpe

  • * Curator
  • Thread Starter
  • Posts: 8822
  • Location: Odessa, TX
  • Live long, and prosper.
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1076 on: Fri, 25 July 2014, 10:34:46 »
Every row and column on the GHpad is broken out to solder pads on the side of the PCB. If your expansion PCB had the column and rows broken out in the same manner, it should be trivial to wire them together and connect to a separate controller board, be it a Teensy or whatever.
KMAC :: LZ-GH :: WASD CODE :: WASD v2 :: GH60 :: Alps64 :: JD45 :: IBM Model M :: IBM 4704 "Pingmaster"

http://jd40.info :: http://jd45.info


in memoriam

"When I was a kid, I used to take things apart and never put them back together."

Offline samwisekoi

  • MAWG since 1997
  • * Administrator
  • Posts: 2479
  • Location: Mt. View, California
  • Sorry, moving houses. Be back ASAP.
    • Tweet samwisekoi
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1077 on: Fri, 25 July 2014, 10:43:23 »
Every row and column on the GHpad is broken out to solder pads on the side of the PCB. If your expansion PCB had the column and rows broken out in the same manner, it should be trivial to wire them together and connect to a separate controller board, be it a Teensy or whatever.

Got it.  Thanks.

Is the reverse true?  Can I wire my expansion PCBs to the GHpad controller?  I can extend the rows by wiring to the GHpad row pads.  Are there places where I could ADD two additional columns?  Going from a 4x6 matrix to a 6x6 matrix?

 - Ron | samwisekoi


I like keyboards and case modding.  Everything about a computer should be silent -- except the KEYBOARD!

'85 IBM F-122/Soarer Keyboard |  Leopold FC200 TKL (Browns) + GH36 Keypad (Browns/Greens) | GH-122 (Whites/Greens) with Nuclear Data Green keycaps in a Unicomp case

Offline jdcarpe

  • * Curator
  • Thread Starter
  • Posts: 8822
  • Location: Odessa, TX
  • Live long, and prosper.
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1078 on: Fri, 25 July 2014, 10:52:21 »
Every row and column on the GHpad is broken out to solder pads on the side of the PCB. If your expansion PCB had the column and rows broken out in the same manner, it should be trivial to wire them together and connect to a separate controller board, be it a Teensy or whatever.

Got it.  Thanks.

Is the reverse true?  Can I wire my expansion PCBs to the GHpad controller?  I can extend the rows by wiring to the GHpad row pads.  Are there places where I could ADD two additional columns?  Going from a 4x6 matrix to a 6x6 matrix?

 - Ron | samwisekoi




I don't think any of the spare pins on the ATmega are broken out to pads on the PCB. :(

But don't quote me on that.
KMAC :: LZ-GH :: WASD CODE :: WASD v2 :: GH60 :: Alps64 :: JD45 :: IBM Model M :: IBM 4704 "Pingmaster"

http://jd40.info :: http://jd45.info


in memoriam

"When I was a kid, I used to take things apart and never put them back together."

Offline samwisekoi

  • MAWG since 1997
  • * Administrator
  • Posts: 2479
  • Location: Mt. View, California
  • Sorry, moving houses. Be back ASAP.
    • Tweet samwisekoi
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1079 on: Fri, 25 July 2014, 12:45:29 »

I don't think any of the spare pins on the ATmega are broken out to pads on the PCB. :(

But don't quote me on that.

[Hits quote button...]

But there ARE spare pins on the ATmega?  Is there a good image of the PCB front and back somewhere?

Worst case I can always remap any of the new keys to unused keys in the existing 24 RC positions.

Thanks!

 - Ron | samwisekoi
I like keyboards and case modding.  Everything about a computer should be silent -- except the KEYBOARD!

'85 IBM F-122/Soarer Keyboard |  Leopold FC200 TKL (Browns) + GH36 Keypad (Browns/Greens) | GH-122 (Whites/Greens) with Nuclear Data Green keycaps in a Unicomp case

Offline samwisekoi

  • MAWG since 1997
  • * Administrator
  • Posts: 2479
  • Location: Mt. View, California
  • Sorry, moving houses. Be back ASAP.
    • Tweet samwisekoi
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1080 on: Fri, 25 July 2014, 18:05:13 »
It looks like I can connect to Pin 20 and 21 here:


Closeup of GHpad v0.8 by regack

WITHOUT using the serial expander, of course.

Column 1-4 are on pins 13-16, so unless these are special pins, it appears to me like I could hook a couple of columns to those pins and mod the firmware accordingly.

Otherwise it looks like direct to SMD pins on the ATmega, which I would like to avoid.

Does anyone know if I could safely connect Columns 5 and 6 to Pins 20 and 21?

 - Ron | samwisekoi
I like keyboards and case modding.  Everything about a computer should be silent -- except the KEYBOARD!

'85 IBM F-122/Soarer Keyboard |  Leopold FC200 TKL (Browns) + GH36 Keypad (Browns/Greens) | GH-122 (Whites/Greens) with Nuclear Data Green keycaps in a Unicomp case

Offline MOZ

  • KING OF THE NEWBIES
  • * Maker
  • Posts: 3969
  • Location: Jo'burg
  • Busy making stuff
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1081 on: Sat, 26 July 2014, 14:20:10 »
No, you can't, those two are to allow the GHPad to be connected to an I2C enabled device, like say the Ergodox, or some other future keyboard that has I2C enabled, so that a dedicated controller MPU is not required on the GHPad and an I/O expander can be used instead.
« Last Edit: Sat, 26 July 2014, 14:23:17 by MOZ »

Offline regack

  • Posts: 655
  • Location: Thessia
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1082 on: Sun, 27 July 2014, 19:02:03 »
I haven't been able to be around much due to... life... but what you could do is repurpose the PB3 (MISO), PB2 (MOSI) & PB1 (SCK) pins from the pads where you could connect an ISP between S3 and S8, they're just as not conveniently located at the edge of the pcb.  I guess that would get you 3 extra rows or columns...



In that clipped picture, to the left of the MCPblahblah silkscreens is the GND pin with MISO below it.  The silkscreen for those is on the front of the PCB, and not the back.




Offline Glod

  • * Elevated Elder
  • Posts: 1905
  • Location: Richmond, Virginia
  • colemak is the way to go
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1083 on: Tue, 09 September 2014, 22:25:22 »
i am not having luck programming my "red scarf" GHPad from the group buy

i made a hex file in the easykeymap app and used flip to flash, flip driver is installed and it shows it erasing and programming sucessfully and validates but when i unplug and plug the keypad back into the computer it does not see it as a keyboard. no input is registered on any key

anyone have a hex file i could try, maybe it has to do with the easykeymap app
GLOD
The Invisible.

Offline MOZ

  • KING OF THE NEWBIES
  • * Maker
  • Posts: 3969
  • Location: Jo'burg
  • Busy making stuff
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1084 on: Wed, 10 September 2014, 04:43:40 »
Try loading using the Teensy app, I have always used that for loading firmware and never had any issues.

Offline geniekid

  • Posts: 757
  • Location: Chicago, IL
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1085 on: Wed, 10 September 2014, 12:13:52 »
i am not having luck programming my "red scarf" GHPad from the group buy

i made a hex file in the easykeymap app and used flip to flash, flip driver is installed and it shows it erasing and programming sucessfully and validates but when i unplug and plug the keypad back into the computer it does not see it as a keyboard. no input is registered on any key

anyone have a hex file i could try, maybe it has to do with the easykeymap app

I had the same problem using metalliqaz's easykeymap.  Ended up using regack's firmware (be sure to read the READMEs).  Not as nice or easy to use as easykeymap, but it works.  Note that I cut my PCB down to 4x5 (don't think this matters but pointing it out in case it does).

Offline whitevivian

  • Posts: 7
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1086 on: Thu, 11 September 2014, 04:31:41 »
Quote
http://www.pabbos.com/38746408917.shtml

there are " Black", "Aluminum Color" .   No "red" Color now.
« Last Edit: Thu, 11 September 2014, 04:34:18 by whitevivian »
usb and keyboards collecter
--------------------------------------
My tumblr for data recovery
computer data recovery

Offline boardcolletor

  • Posts: 10
    • hardware and accessories for computers and pad
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1087 on: Wed, 17 September 2014, 23:22:18 »
Quote
http://www.pabbos.com/38746408917.shtml

there are " Black", "Aluminum Color" .   No "red" Color now.

Seems not bad.
Love geekhack
mainboard, mouse, keyboard
hardware recovery and others

Offline whiskytango

  • Posts: 576
  • Location: Birmingham, Alabama
  • Don't touch the trim
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1088 on: Thu, 18 December 2014, 10:24:14 »
MOZ, did you ever release cad files for an acrylic ghpad case in a 4x5 size?

EDIT: Or does anyone have a source for a 4x5 acrylic case?
« Last Edit: Thu, 18 December 2014, 10:30:14 by whiskytango »
I stay busy with work and family these days, but I'm still around, lurking.

Offline MOZ

  • KING OF THE NEWBIES
  • * Maker
  • Posts: 3969
  • Location: Jo'burg
  • Busy making stuff
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1089 on: Thu, 18 December 2014, 10:27:41 »
I'm not sure. I'll check on my system and post them in any case.

Offline breh

  • Posts: 3
Re: GHpad FTW (10-Key Pad for GH60)
« Reply #1090 on: Tue, 25 August 2015, 16:01:31 »
First I'd like to apologize if I shouldn't have necro'd a thread from over a year ago, but I wasn't sure if this post warranted a new topic. I've tried my best to follow this thread through in my course of building a GHpad.

I am still looking for a case for the thing since TaoBao was out of stock for the nice acrylic cases. I was curious if anyone had CAD models for either a 2-piece plate case (like the one JDCarpe made for TheChemist https://geekhack.org/index.php?topic=38963.msg1324791#msg1324791) or the multi-piece acrylic that MOZ made (https://geekhack.org/index.php?topic=38963.msg1167300#msg1167300); I'd also be interested in potentially buying one if available.

Recently I bought a GHpad board from TaoBao called "AMJ Pad". It looks like a modified version of regack's board with resistor positions for optional LEDs at every switch position as well as additional LED positions around the perimeter of the board. I wanted to get your knowledgeable opinions before I assume these to be true, and I also had a few questions.
The boards can be seen here:
109491-0109493-1

Below I've labeled a few positions on the board I had a question about:
109495-2109497-3
  • On the bottom side of the board there's a switch labeled "REST" (on the reverse). This seems to be the same switch seen at the top center of the regack design - what is this switch for?
  • There's a SMD solder point below the switch called "LED", anyone know what the LED might be for?
  • There's two sets of Through-hole solder points labeled R1-R5 and C1-C4 in the highlighted markings "Unknown Pins #2 and #3". I'm assuming these are the row and column break outs mentioned by JDCarpe a few posts up.
  • On the top side there's a set of 6 through hole solder points for "MOSI SCK" in the box "Unknown Pins #1". Not sure what those are for either

Just to recap what I am currently assuming:
There's 24 switch positions on this board since it's basically the 6x4 layout by regack complete with the sort of breakaway bottom row. Each key position has a diode SMD solder point designated by D1-D24. Diodes are required for key operation. I'm doing a 21-key config so I only need to solder diodes for the relevant switches. I will probably solder all 24 on, since I have no idea which diode corresponds to which switch position.

Additionally each switch position has a resistor solder point for optional LEDs on switches in positions RL1-24. If I don't have an LED on a switch, the resistor is optional. Resistor sizing depends on the LED voltage needed.

There are 15 LED positions on the perimeter of the board. Each position has 4 solder pads, 2 for the resistor, 2 for the LED. I have no idea if the resistor goes first or the LED. I have no idea what orientation the polarity is for those solder points for the LEDs. The solder mask is slightly more bulbous on one side, maybe this means something.

Everything above is stated as my interpretation, not fact; please correct me if I'm wrong!
Thank you very much for reading.

Regards,
breh

« Last Edit: Tue, 25 August 2015, 16:03:33 by breh »
